Victor Reinz - How to replace a Cylinder Head Gasket

The expert removal of a defective Cylinder-head Gasket and the successful installation of a new one isn’t an easy part when it comes to engine repairs. This video shows the necessary step-by-step work processes – from removing the cylinder-head and cleaning the sealing surfaces, to tightening the new cylinder-head bolts.

1 Comments

MAHLE Innovation

Shaping the future with innovative strength

As one of the world’s 20 largest suppliers and a development partner to the automotive industry, MAHLE offers innovative mobility solutions that stand for clean air, fuel efficiency, and driving pleasure.

Read More 0 Comments

Goetze History

Goetze is one of the longest established names in automotive, delivering technically advanced components that significantly lower oil consumption and reduce emissions.

Read More 0 Comments

DO's and DON'ts: Piston & Piston Rings

  • Piston pins should not be hammered into pin hole
  • Piston rings should not be mounted by hand, always use a good quality ring installing tool/expander
  • While finally installing the piston & ring assembly in the cylinder, care should be taken that the ring gaps are not aligned and are at equal angles with respect to each other
  • Make sure to sufficiently lubricate the piston/ring while inserting in bore, this is required for initial lubrication
  • Use a good quality ring compressor while fitting the piston/ring in the cylinder
  • The ‘top’ marking on the ring indicates that it should be installed with ‘top’ mark towards top of the piston
  • In oil rings with springs, the spring joint should be exactly opposite to the end gap of the end gap
  • A good quality circlip plier should be used for installation, also ensure proper fitment of the circlip in one groove and keep the open end downwards in position
  • Do not check the tension of the rings by repeatedly pressing it by hand, it can easily disturb the alignment of the end gaps


PISTON RING ASSEMBLY ERRORS



Assembly errors can and will contribute to high base pressure and can cause oil to bypass the rings. This can create a build-up of abrasive carbon, which can lead to ring scuffing, a loss of ring control, and possible piston seizure.



PROBABLE CAUSES

  • Piston ring end gap misalignment
  • Expander end gap is same as oil ring end gap

When piston failure has occurred, it is extremely important to thoroughly inspect all of the engine components during the disassembly procedure. This thorough inspection will lead you to the possible cause or causes of the piston failure and will ensure that the same piston failure doesn’t occur once the engine is repaired and placed back into service by your customer.

Read More 2 Comments

MANN-FILTER MOTORSPORT - LOVING CHALLENGES

"The exciting and emotional motor sports season 2016, with the VLN race and the 24-hour race at the Nürburgring has shown us that MANN-FILTER and motor sports is a perfect match. Why? Our filters don’t just have to work reliably in everyday automotive applications, but also withstand extremely high loads on the race track. The challenge of proving this on a regular basis and our excitement about developing and manufacturing high-quality filter systems and components is what drives us forward. The objectives of our involvement in 2017 are therefore clearly formulated: MANN-FILTER intends to delight, be successful and awaken emotions in motor sports as well."


Read More 0 Comments
